1.  Features no mechanical moving parts, corrosion resistance, stability, reliability, and a long service life, with no special maintenance required over extended operation periods.

2.  Employs a 16-bit microprocessor chip, boasting high integration, compact size, excellent performance, and robust overall functionality.

3. It integrates the flow probe, microprocessor, pressure and temperature sensors into a compact structure, and automatically tracks and compensates in real time and corrects the compression factor

4.  Utilizes dual detection technology to enhance detection signal strength and suppress interference caused by pipeline vibrations.

5.  Equipped with a dot matrix LCD display in Chinese, it directly shows instantaneous volume flow rate under working conditions, standard volume flow rate, total volume, as well as medium pressure and temperature parameters.

6.  Adopting EEPROM technology, parameter setting is facilitated and can be permanently saved, with the capacity to store historical data for up to one year.

7.  The converter outputs frequency pulse, 4-20mA analog signals, and is equipped with an RS485 interface, allowing direct networking with a computer.

8.  Offers multiple physical parameter alarm outputs, with users having the flexibility to select any one as per their requirements.

Model & Specifications: DN15~DN300

Measurement Medium: Common steady-state gases

Turn-down Ratio: 1: (15~40)

Accuracy Class: 0.5~1.5 Class

Medium Temperature: -40~150°C

Medium Pressure: (1.6~100) MPa

Power Supply: Lithium Battery / DC24V

Explosion-proof Rating: Ex ia II C T6 Ga / Ex d IIC T6 Gb (Flameproof)

Protection Class: IP65

Material: Aluminum Alloy, Stainless Steel

Output Signal: 4-20mA (Binary, Trinary, or Quaternary selectable) / HART

 RS-485 (Modbus RTU)

 2 Normally Open Alarm Outputs, Proportional Output

Nominal Diameter (mm): DN15~DN200

Material of Instrument: Stainless Steel 1Cr18Ni9Ti or Aluminum Alloy

Nominal Pressure (MPa): 1.6~42

Accuracy Class: 1.0 Class, 1.5 Class

Ambient Temperature (℃): -30~65

Ambient Humidity: 5%~95%

Medium Temperature (℃): -20~80

Output Types: Pulse Signal, RS485 Communication, 4-20mA, Switch Signal

Power Supply:

a) External Power, +24VDC ±15%

b) Internal Power, 1 set of 3.6V Lithium Battery

Average Power Consumption:

a) External Power: 2W

b) Internal Power: 1mW

Signal Line Interface: Internal Thread M20x1.5

Explosion-proof Grade: ExdIIBT6

Protection Grade: IP65
