1. Wide measurement flow range.

2.Multi-target software calibration technology, intelligent self-check, and self-diagnosis functions, with fault alarm.

3. Menu-driven software design for easy operation, with password protection to prevent misuse.

4. Integrated temperature and pressure compensation function, capable of measuring the instantaneous flow rate and cumulative flow rate of fluids.

5. Based on Modbus protocol, with wired 485, 4-20mA signal output with HART, pulse/frequency.

6. Simultaneous display of instantaneous flow rate (m3/h), cumulative flow rate (m3), and instrument communication status. Strong seismic performance, high pressure resistance, and high safety.

Nominal Diameter (mm): DN10 to DN2200

Nominal Pressure (MPa): 1.6 to 42 MPa

Maximum Temperature of Measured Medium: Hard Rubber Lining 90°C; Soft Rubber Lining 90°C; PTFE Lining 180°C

Measured Medium: Conductive Liquids

Accuracy Class: 0.5 Class, 1.0 Class (Special Design up to 0.3 Class) for Pipeline Type; 1.5 Class (Special Design up to 1.0 Class) for Insertion Type

Relative Humidity: ≤85% RH

Lining Material: Rubber, PTFE, etc.

Electrode Material: Standard: Stainless Steel 1Cr18Ni9Ti; Special: Hastelloy B, Hastelloy C

Protection Class: IP65 - Water Jet Resistant; IP68 - Submersible

Power Supply: AC Voltage 220VAC, Tolerance ±15%, Frequency 50Hz, Tolerance ±5%; or DC: 24VDC (18-36VDC)

Installation Type: Integral Type, Separated Type

Power Consumption: Utilizes ultra-low power consumption chips, with the total power consumption below 6W

Output Signal: RS485, Modbus Protocol, HART Protocol

Long-term Working Stability: Temperature Influence 0.01/°C, Coil Temperature Rise Below 3°C
